KEB COMBIVERT F5 Reference Manual

257
DG - Diagnostics Parameters (Combivis only)
The Mode indicates the operating state of the keypad operator.
Value: Description:
5 Idle - Program
6 Idle
21 Fault Reset
22 Fault
32 Check Special Function
34 Activate Special Function
37 Tune Motor Pre
38 Tune SPI Pre
39 Tune Pole Pre
40 Tune Encoder Pre
41 Tune Inertia Pre
42 Tune Overspeed Pre
43 Tune Safety Pre
48 No Direction (LS)
50 Brake Off Up
52 Brake Off Down
54 Start Delay
56 Tune Motor
57 Tune SPI
58 Tune Pole
64 Determine Speed
68 External Prole Run
72 Releveling
80 Stopping
82 Brake On
84 End Run Reset
86 Special Function Reset
96 End Run Idle
97 Tune Motor Post Fail
98 Tune Motor Post OK
99 Tune SPI Post Fail
100 Tune SPI Post OK
101 Tune Pole Post Fail
102 Tune Pole Post OK
103 Tune Encoder Post
104 Tune Inertia Post
105 Tune Overspeed Post
106 Tune Safety Post
255 Not Congured
DG51
Mode
