Parameter Reference
I = Induction Geared, IX = Induction Gearless, P = PM Geared, PX = PM Gearless
Para. Name
Hex v1.72 Motor/Gear Type
Setting
Options
NUM
Range Units Default
Pass
Level
I IX P PX Min. Max. Imp. Met.
LE35 Encoder 2 Output PPR
05A3 US83
Source
Channel 1
Channel 2
Actual Value
Reserved
Actual Value
256
512
1024
2048
Division
Direct
2
4
8
16
32
64
128
0
1
2
3
0
4
8
12
0
16
32
48
64
80
96
11 2
- - -
Channel 1
Direct
OEM
LE36 PT1 Time Encoder 2
05A4 - - - 0 255 ms 0 Adjuster
LE37 Encoder 2 Multiplier
05A5 - - - 0 13 ms 2 Adjuster
LE38 Encoder 2 Numerator
05A6 - - - -2147483648 2147483647 ms 1 Adjuster
LE39 Encoder 2 Denominator
05A7 - - - -2147483648 2147483647 ms 1 Adjuster
LN01 Traction Sheave Diameter
0781 LF21
- - 3.94 62.99 in - 24.00
Basic
- - 100 1600 - mm 610
LN02 Gear Reduction Ratio
0782 LF22 - - 1.00 250.00 x:1 30.00 Basic
LN03 Roping Ratio
0783 LF23 - - 1 4 x:1 1 Basic
LN04 Load
0784 LF24 - -
0 30000 lb - 0
Basic
0 13607 - kg 0
LN05 Estimated Gear Ratio
0785 LF25
RO RO RO RO
- - 0.00 250.00 x:1 Calculated Basic
LS00 Zero Speed Offset
0880 - -
- 0 2 ft/min - 0
OEM
- 0 0.010 - m/s 0
LS01 Leveling Speed
0881 LF41
*upper limit increases to 59fpm
when LX50 is active
- 0 25/59* ft/min - 4
Basic
- 0.00 0.13 - m/s 0.02
LS02 High Speed
0882 LF42 -
- 0 1600 ft/min - 0
Basic
- 0.00 8.00 - m/s 0.00
LS03 Inspection Speed
0883 LF43 -
- 0 150 ft/min - 30
Basic
- 0.00 0.63 - m/s 0.15
LS04 Correction Speed
0884 LF44 -
- 0 50 ft/min - 0
Basic
- 0.00 0.25 - m/s 0.00
LS05 Intermediate Speed 1
0885 LF45 -
- 0 1600 ft/min - 0
Basic
- 0.00 8.00 - m/s 0.00
LS06 Intermediate Speed 2
0886 LF46 -
- 0 1600 ft/min - 0
Basic
- 0.00 8.00 - m/s 0.00
LS07 Intermediate Speed 3
0887 LF47 -
- 0 1600 ft/min - 0
Basic
- 0.00 8.00 - m/s 0.00
LS08 Earthquake Speed
0888 - -
- 0 150 ft/min - 0
Basic
- 0.00 0.76 - m/s 0.00
LS09 Emergency Power Speed
0889 - -
- 0 1600 ft/min - 0
Basic
- 0.00 8.00 - m/s 0.00
LS10 Battery Operation Speed
088A - -
- 0 50 ft/min - 0
Basic
- 0.00 0.25 - m/s 0.00
