KEB COMBIVERT F5

315
Parameter Reference
I = Induction Geared, IX = Induction Gearless, P = PM Geared, PX = PM Gearless
Para. Name
Hex v1.72 Motor/Gear Type
Setting
Options
NUM
Range Units Default
Pass
Level
I IX P PX Min. Max. Imp. Met.
LS47
Intermediate Speed 3
Correction
08AF - -
- 0.0 6.0 in - 0.0
Adjuster
- 0.0 15.2 - cm 0.0
LS48 ESD/ETS Deceleration
08B0 - -
- 0.30 12.00 ft/sec
2
- 4.00
Adjuster
- 0.091 3.659 - m/s
2
1.220
LS49 ESD/ETS Jerk
08B1 - -
- 0.30 32.00 ft/sec
3
- 4.00
Adjuster
- 0.091 9.756 - m/s
3
1.220
LS50 Acceleration Inspection
08B2 - -
- 0.30 12.00 ft/sec
2
- 2.00
Adjuster
- 0.091 3.662 - m/s
2
0.613
LS51 Start Jerk Inspection
08B3 - -
- 0.30 32.00 ft/sec
3
- 2.00
Adjuster
- 0.091 9.759 - m/s
3
0.613
LS52 Accel. Jerk Inspection
08B4 - -
- 0.30 32.00 ft/sec
3
- 2.00
Adjuster
- 0.091 9.759 - m/s
3
0.613
LS53 Deceleration Inspection
08B5 - -
- 0.30 12.00 ft/sec
2
- 2.00
Adjuster
- 0.091 3.662 - m/s
2
0.613
LS54 Decel. Jerk Inspection
08B6 - -
- 0.30 32.00 ft/sec
3
- 2.00
Adjuster
- 0.091 9.759 - m/s
3
0.613
LS55 Stop Jerk Inspection
08B7 - -
- 0.30 32.00 ft/sec
3
- 2.00
Adjuster
- 0.091 9.759 - m/s
3
0.613
LL01 Motor Tuning
0981 LF3
Off
Start
0
1
- - - - Off Basic
LL02 Tuning Current
0982 - - -
NA NA NA NA NA -
10 100 % 100 Basic
LL05 SPI
0985 LF3
- - NA NA NA NA NA -
Off
Start
0
1
- - - - Off Basic
LL06
Encoder Pole Position
Learn
0986 LF3
NA - NA NA NA NA NA -
Off
Start
0
1
- - - - Off Basic
LL07 Encoder Synchronization
0987 LF3
Off
Start
0
1
- - - - Off Basic
LL10 Inertia Learn
098A LF3
Off
Start
0
1
- - - - Off Basic
LL15 Overspeed Test
098F LF3
Off
Start
0
1
- - - - Off Basic
LL16 Overspeed Test Speed
0990 - -
- 0 2400 ft/min - 0
Basic
- 0.000 12.190 m/s - 0.000
LL17 Safety Release
0991 -
Off
Start
0
1
- - - - Off Basic
LL18 NTSD Tune Mode
0992 -
Off
Start
0
1
- - - - Off OEM
LC01 Control Mode
0B81 LF30
Open Loop V/Hz
Open Loop Vector
Closed Loop FOC
Closed Loop Analog Pretorque
Closed Loop Digital Pretorque
Closed Loop Synth. Pretorque
0
1
2
3
4
5
- - - -
Closed Loop
FOC
Basic
LC02 Speed Gain Optimization
0B82 - - - 0 25 - - 0 Basic
LC03 KP Speed Acceleration
0B83 ALF31 - - 1 50000 - - 3000 Adjuster
LC04 KP Speed Deceleration
0B84 dLF31 - - 1 50000 - - 3000 Adjuster
LC05 KP Speed Pretorque
0B85 PLF31 - - 1 50000 - - 3000 Adjuster
LC08 KI Speed Acceleration
0B88 ALF32 - - 1 25000 - - 250 Adjuster
LC09 KI Speed Deceleration
0B89 dLF32 - - 1 25000 - - 250 Adjuster
LC10 KI Speed Pretorque
0B8A PLF32 - - 1 30000 - - 500 Adjuster
LC11 KI Speed Offset Accel
0B8B ALF33 - - 0 20000 - - 3000 Basic
LC12 KI Speed Offset Decel
0B8C dLF33 - - 0 20000 - - 1000 Basic
