KEB COMBIVERT F5 Reference Manual

321
Parameter Reference
I = Induction Geared, IX = Induction Gearless, P = PM Geared, PX = PM Gearless
Para. Name
Hex v1.72 Motor/Gear Type
Setting
Options
NUM
Range Units Default
Pass
Level
I IX P PX Min. Max. Imp. Met.
DG05 Actual Torque
1185h ru12
RO RO
- -
-2214.0 2214.0 lb-ft - 0.0
-3000.0 3000.0 - Nm 0.0
RO RO
-22140 22140 lb-ft - 0
-30000 30000 - Nm 0
DG06 Motor Current
1186h
ru15
LF93
RO RO RO RO
- - -3200.0 3200.0 Amps 0.0
DG07 Motor Speed
1187h
ru9
LF89
RO RO
- -
-4000 4000
rpm
0
RO RO
-500.0 500.0 0.0
DG08 DC Bus Voltage
1188h
ru18
LF95
RO RO RO RO
- - 0 1000 Volts 0
DG09 Magnetizing Current
1189h ru87
RO RO RO RO
- - -3200.0 3200.0 A 0.0
DG10 Modulation Grade
118Ah ru42
RO RO RO RO
- - 0 110 % 0
DG11 Output Status
118Bh
ru25
LF83
RO RO RO RO
None
O1
O2
RLY1
RLY2
0
1
2
4
8
0 15 - - 0
DG16 Output Condition State
1190h ru23
RO RO RO RO
None
Condition 0
Condition 1
Condition 2
Condition 3
Condition 4
Condition 5
Condition 6
Condition 7
0
1
2
4
8
16
32
64
128
0 255 - - 0
DG17 Output Frequency
1191h
ru3
LF97
RO RO RO RO
- - -400.0 400.0 Hz 0.0
DG18 Output Voltage
1192h ru20
RO RO RO RO
- - 0 1000 Volts 0
DG19 Parameter Set
1193h ru26
RO RO RO RO
- - 0 7 - - 0
DG20 Raw Pattern
1194h ru27
RO RO RO RO
- - -10.00 10.00 VDC 0.00
DG21 Processed Pattern
1195h ru28
RO RO RO RO
- - -10.00 10.00 VDC 0.00
DG30 Peak DC Volts
119Eh
ru19
LF96
RO RO RO RO
- - 0 1500 Volts 0
DG31 Peak Current
119Fh
ru16
LF94
RO RO RO RO
- - -3200.0 3200.0 Amps 0.0
DG32 Peak Speed
11A0h ru85
RO RO RO RO
- -
0 2500 ft/min - 0
0.000 12.700 - m/s 0.000
DG33 Raw Pretorque
11A1h ru29
RO RO RO RO
- - -10.00 10.00 VDC 0.00
DG34 Post Pretorque
11A2h ru30
RO RO RO RO
- - -10.00 10.00 VDC 0.00
DG35 Analog Output 1
11A3h ru34
RO RO RO RO
- - -10.00 10.00 VDC 0.00
DG36 Analog Output 2
11A4h ru36
RO RO RO RO
- - -10.00 10.00 VDC 0.00
DG37 Heatsink Temperature
11A5h ru38
RO RO RO RO
- - 0 120 Degree Celsius 0
DG38 Motor Temperature
11A6h ru46
RO RO RO RO
- -
0: T1-T2
Closed
150 Degree Celsius 0
DG39 Carrier Frequency
11A7h ru45
RO RO RO RO
2 kHz
4 kHz
8 kHz
12 kHz
16 kHz
0
1
2
3
4
2 16 kHz 0
DG40 Electric Power
11A8h ru92
RO RO RO RO
- - -320.0 320.0 kW 0.0
DG41 Motor Power
11A9h ru81
RO RO RO RO
- - -320.0 320.0 kW 0.0
DG42 Braking Energy
11AAh ru91
RO RO RO RO
- - 0 65535 kWh 0
DG43 Power On Counter
11ABh ru40
RO RO RO RO
- - 0 65535 hr 0
DG44 Run Time Counter
11ACh ru41
RO RO RO RO
- - 0 65535 hr 0
DG45 Overload Counter
11ADh ru39
RO RO RO RO
- - 0 100 % 0
DG46 Drive Load
11AEh
ru13
LF87
RO RO RO RO
- - 0 500 % 0
DG47 Peak Load
11AFh ru14
RO RO RO RO
- - 0 500 % 0
DG49 Signed Elevator Speed
11B1h
RO RO RO RO
-
- -2000 2000 ft/min - 0
- -10.160 10.160 - m/s 0
