WAVE EQUALIZER
By pressing the F8 button on the DSP page, you
can access the WAVE EQUALIZER screen, as
shown in Figure 249. Here you can select the WAVE
EQUALIZER type to set as equalization of the WAVE
Player.
5 Wave Equalizer Presets are available. Just press
one of the F1-F5 buttons to select the corresponding
Wave Equalizer type:
Wave Equal.1 ... Wave Equal.5
When you activate an Wave Equalizer Preset you can
set the option Lock:On/Off as for the previous effects.
By pressing the EDIT button on the front panel, you
can access the parameters of the selected Wave
Equalizer Preset, as shown in Figure 249. The
parameters are identical for all the five Wave Equalizer
effects:
F1– Wave Equalizer (choose from 1 to 5)
F2– BASS FREQ: bass frequency (values 50–990 Hz)
F3– TREBLE FREQ: high frequency (values 1030–
16130 Hz)
F4– BASS GAIN: bass gain (values +/-12 dB)
F5– TREBLE GAIN: high gain (values +/-12 dB)
F7– VOICE ADJUST: frequency adjustment for the
vocal part reduction function (values 1-300). See
below.
Press the USER 1 button (ACTIVE) to enable the
Wave
Equalizer
.
The USER 2 button (DEFAULT) resets the
parameters to the default values.
By pressing the USER 3 button (VOICE ON/OFF)
as shown by the arrow on Figure 250, you can
reduce the vocal part of the current WAVE file. You
can adjust the VOICE ADJIUST and the bass/high
gain parameters, in order to reach the best result
in the vocal reduction.
Press the F1 button (LEAD MUTE) when the WAVE
Player is running (Figure 251) to activate the vocal
reduction function.
After you set the parameters you can to store the
custom Wave Equalizer by pressing the USER 5
button (SAVE) or the SAVE button on the front panel.
A brief message SAVE DATA TO DISK will appear.
Figure 249
Figure 250
Figure 251
