Features of your vehicle Instrument cluster
Do not operate the engine within
the tachometer's RED ZONE. This
may cause severe engine damage.
Engine coolant temperature gauge
Type A
Type B
This gauge indicates the tempera
-
ture of the engine coolant when the
ignition switch or ENGINE START/
STOP button is ON.
If the gauge pointer moves beyond
the normal range area toward the
"H" position, it indicates overheating
that may damage the engine.
Do not continue driving with an
overheated engine. If your vehicle
overheats, refer to "If the engine
overheats" on page 7-8.
Never remove the radiator cap when
the engine is hot. The engine cool
-
ant is under pressure and could
severely burn. Wait until the engine
is cool before adding coolant to the
reservoir.
