Maintenance Light bulbs
Replacing license plate lamp (Bulb
type)
1. Turn off vehicle and disconnect
the negative terminal from the
battery.
2. Using a screwdriver, gently pry
the lamp assembly.
3. Remove the bulb by pulling it
straight out.
4. Install a new bulb in the socket.
5. Install the lamp assembly.
Be careful not to dirty or damage
the lens, lens tab, and plastic hous
-
ings.
Replacing map lamp (Bulb type)
Prior to working on the Interior
lamps, ensure that the "OFF" button
is depressed to avoid burning your
fingers or receiving an electric
shock.
1. Using a flat-blade screwdriver,
gently pry the lens cover from
lamp housing.
2. Remove the bulb by pulling it
straight out.
3. Install a new bulb in the socket.
4. Align the lens cover tabs with the
lamp housing notches and snap
the lens into place.
Be careful not to dirty or damage
the lens, lens tab, and plastic hous
-
ings.
