Engine compartment
Smartstream D2.2 (Diesel)
* The actual engine room in the vehicle may differ from the illustration.
1. Engine coolant reservoir 8-33
2. Brake fluid reservoir 8-36
3. Air cleaner 8-39
4. Engine oil filler cap 8-30
5. Engine oil dipstick 8-30
6. Windscreen washer fluid reservoir 8-38
7. Fuse box 8-62
8. Negative battery terminal 7-6, 8-48
9. Positive battery terminal 7-6, 8-48
