Safety features of your vehicle Seat
2nd row, 3rd row seat (for 11 seats)
3rd row seat (for 7,8 seats)
4th row seats (for 11 seats)
To remove the headrest:
1. Raise it as far as it can go then
press the release button (1)
whilst pulling the headrest up (2).
To reinstall the headrest:
1. Put the headrest poles (3) into
the holes whilst pressing the
release button (1).
2. Adjust it to the appropriate
height.
Make sure the headrest locks in
position after adjusting it to prop
-
erly protect the occupants.
After installing the headrest, make
sure that it is installed in the right
direction.
A headrest installed reversely could
increase whiplash injury during rear
impact.
Do not remove the 2nd row out
-
board headrest. It cannot be
removed completely due to the
cable installed for headrest auto
folding function.
