Post-Discharge Maintenance
06-236115-001 6-17 October 2014
6-4.4 Nitrogen Cylinder Installation
1. Install the nitrogen cylinder in position in the mounting bracket.
2. Tighten sufficiently to hold cylinder in place while allowing cylinder enough free play to be
manually rotated.
3. Turn the cylinder until the cylinder valve discharge outlet is in the desired position.
4. Securely tighten the mounting bracket clamps and hardware.
5. Remove the pipe plug, reconnect the adapter (P/N WK-699205-010) and flexible actuation
hose or tubing to the cylinder valve outlet port.
6. Remove the protective cap from the cylinder valve actuation port.
7. Install the control head to the cylinder valve and tighten securely.
CAUTION
The nitrogen cylinder must be positioned so that the control head, when
installed, is readily accessible and cannot be obstructed during manual
operation.
WARNING
Ensure the control head is in the SET position (that is, the actuating pin is in the
fully retracted or SET position). Failure to do so will cause the nitrogen cylinder
to discharge when the control head is installed.
