Kidde Fire Systems ECS User Manual

Component Description
October 2014 3-8 06-236115-001
Table 3-3. Dimensions, HFC-227ea Cylinder/Valve Assemblies for Vertical Installation Only
Part Number Valve w/LLI
Height Diameter
Volume
Valve
Outlet
Height
CA B
in. m in. m
ft.
3
m
3
in. m
90-10001X-001 1½" No 17.3 0.44 7.07 0.18 0.167 0.0047 13.3 0.33
90-10002X-001 1½" No 24.97 0.64 7.07 0.18 0.286 0.0081 21 0.53
90-10004X-001 1½" No 26.76 0.68 9 0.23 0.572 0.0162 22.8 0.58
90-10007X-001 1½" No 38.83 0.99 9 0.23 1 0.0283 34.9 0.89
90-100121-001 1½" Yes 35.93 0.92 12.75 0.33 1.788 0.0506 32 0.81
90-100125-001 1½" No 35.93 0.92 12.75 0.33 1.788 0.0506 32 0.81
90-100200-101 2" No 52.75 1.34 12.75 0.33 2.859 0.081 47.5 1.21
90-100201-101 2" Yes 52.75 1.34 12.75 0.33 2.859 0.081 47.5 1.21
90-100350-001 2" No 58.36 1.49 16 0.41 5 0.1416 53.1 1.35
90-100351-001 2" Yes 58.36 1.49 16 0.41 5 0.1416 53.1 1.35
90-100600-001 2½" No 56.72 1.45 22 0.56 8.572 0.2427 50.5 1.28
90-100601-001 2½" Yes 56.72 1.45 22 0.56 8.572 0.2427 50.5 1.28
90-100600-100 3" No 58 1.47 22 0.56 8.68 0.246 50.5 1.28
90-100601-100 3" Yes 58 1.47 22 0.56 8.68 0.246 50.5 1.28
90-100900-001 3" No 70 1.78 24 0.61 13 0.368 62 1.57
90-100901-001 3" Yes 70 1.78 24 0.61 13 0.368 62 1.57
