Component Description
October 2014 3-6 06-236115-001
If desired, the 125, 200, 350, 600 and 900 lb. cylinders can be provided with an integral Liquid
Level Indicator (see Paragraph 3-3.2).
Table 3-1. Container Temperature-Pressure Correlation
(Based on a cylinder fill density of 70 lb./ft.
3
or 1121 kg/m
3
)
Temperature
Nominal Charge,
Pressure
°F °C PSIG Bar
32 0 288 19.9
40 4.4 303 20.9
50 10 321 22.2
60 15.6 340 23.5
70 21.1 360 24.8
80 26.7 381 26.3
90 32.2 402 27.7
100 37.8 425 29.3
110 43.3 449 31
120 48.9 475 32.7
130 54.4 502 34
Table 3-2. Cylinder, Equivalent Lengths
Part Number Nomenclature
Discharge
Outlet
Equivalent
Length w/o Flex
Hose
Equivalent
Length w/
Flex Hose
ft. m ft. m
90-100010-001 10 lb. Cylinder 1½" 61.8 18.84 65 19.81
90-100020-001 20 lb. Cylinder 1½" 61.8 18.84 65 19.81
90-100040-001 40 lb. Cylinder 1½" 61.8 18.84 65 19.81
90-100070-001 70 lb. Cylinder 1½" 61.8 18.84 65 19.81
90-10012X-001 125 lb. Cylinder 1½" 61.8 18.84 65 19.81
90-10020X-001 200 lb. Cylinder 2" 59 17.98 65 19.81
90-10035X-001 350 lb. Cylinder 2" 59 17.98 65 19.81
90-10060X-001 600 lb. Cylinder (old style) 2½" 59 17.98 65 19.81
90-10060X-100 600 lb. Cylinder (new style) 3" 50 15 80 24
90-10090X-001 900 lb. Cylinder 3" 50 15 80 24
