Kidde Fire Systems ECS User Manual

Parts List
06-236115-001 7-9 October 2014
7-3.2 UL Listed 180 Degree Nozzles:
Note: An additional nozzle finish has been added for a special application. This is a nickel plated nozzle
designed to the specifications of the brass version which is FM Approved. The part numbers are
exact to that below except for the sixth digit which is a “3” instead of a “0”.
Area (in
2
)
UL Listed 180 Degree Nozzles
1/2 in NPT 3/4 in NPT 1 in NPT 1-1/4 in NPT 1-1/2 in NPT 2 in NPT
0.0770 90-194013-109
0.0810 90-194013-111
0.0820 90-194013-113
0.0875 90-194013-116
0.0931 90-194013-120
0.1030 90-194013-125
0.1072 90-194013-129
0.1190 90-194013-136
0.1289 90-194013-141
0.1342 90-194013-144 90-194014-144
0.1384 90-194013-147 90-194014-147
0.1428 90-194013-150 90-194014-150
0.1605 90-194013-156 90-194014-156
0.1694 90-194013-161 90-194014-161
0.1779 90-194013-166 90-194014-166
0.1909 90-194013-172 90-194014-172
0.2049 90-194014-177
0.2113 90-194014-180
0.2177 90-194014-182 90-194015-182
0.2215 90-194014-185 90-194015-185
0.2313 90-194014-189 90-194015-189
0.2405 90-194014-194 90-194015-194
0.2597 90-194014-199 90-194015-199
0.2744 90-194014-206 90-194015-206
0.3005 90-194014-213 90-194015-213
0.3080 90-194014-219 90-194015-219
0.3128 90-194014-221 90-194015-221
0.3364 90-194014-228 90-194015-228
0.3504 90-194015-234
0.3623 90-194015-238
0.4039 90-194015-246 90-194016-246
