Kidde Fire Systems ECS User Manual

Parts List
06-236115-001 7-7 October 2014
7-3 DISCHARGE NOZZLES
7-3.1 UL Listed 360 Degree Nozzles
Note: An additional nozzle finish has been added for a special application. This is a nickel plated nozzle
designed to the specifications of the brass version which is FM Approved. The part numbers are
exact to that below except for the sixth digit which is a “3” instead of a “0”
.
WARNING
Only listed Kidde ECS System HFC-227ea nozzles are to be used on Kidde ECS
Systems. Failure to comply with this WARNING can result in unpredictable
agent distribution.
Area (in
2
)
UL Listed 360 Degree Nozzles
1/2 in NPT 3/4 in NPT 1 in NPT 1-1/4 in NPT 1-1/2 in NPT 2 in NPT
0.0774 90-194023-111
0.0802 90-194023-113
0.0845 90-194023-116
0.0905 90-194023-120
0.0982 90-194023-125
0.1037 90-194023-129
0.1162 90-194023-136
0.1240 90-194023-141
0.1303 90-194023-144
0.1358 90-194023-147 90-194024-147
0.1404 90-194023-150 90-194024-150
0.1534 90-194023-156 90-194024-156
0.1629 90-194023-161 90-194024-161
0.1731 90-194023-166 90-194024-166
0.1856 90-194023-172 90-194024-172
0.1968 90-194023-177 90-194024-177
0.2035 90-194023-180 90-194024-180
0.2080 90-194023-182 90-194024-182
0.2150 90-194023-185 90-194024-185
0.2244 90-194024-189 90-194025-189
0.2353 90-194024-194 90-194025-194
0.2488 90-194024-199 90-194025-199
0.2653 90-194024-206 90-194025-206
0.2851 90-194024-213 90-194025-213
0.3007 90-194024-219 90-194025-219
0.3069 90-194024-221 90-194025-221
0.3266 90-194024-228 90-194025-228
0.3440 90-194024-234 90-194025-234
0.3559 90-194024-238 90-194025-238
0.3802 90-194025-246 90-194026-246
