Kidde Fire Systems ECS User Manual

Design and Installation
06-236115-001 4-23 October 2014
Table 4-9. Installation of the Flexible Hose Directly into System Piping, English (inches)
Table 4-10. Installation of the Flexible Hose Directly into System Piping, Metric (millimeters)
Cylinder Capacity
Dimensions in inches
ABC
10 lb 14 5/8 16 3/4 1 1/2
20 lb 14 5/8 16 3/4 1 1/2
40 lb 14 5/8 16 3/4 1 1/2
70 lb 14 5/8 16 3/4 1 1/2
125 lb 14 5/8 16 3/4 1 1/2
200 lb 19 21 3/4 2
350 lb 19 21 3/4 2
600 lb (old style) 29 5/8 32 3/4 2 1/2
600 lb (new style) 33 36 3
900 lb 33 36 3
Dimensions A and B must be maintained in order to
obtain a smooth radius in flexible loop.
Cylinder Capacity
Dimensions in
millimeters
ABC
10 lb 371 425 38
20 lb 371 425 38
40 lb 371 425 38
70 lb 371 425 38
125 lb 371 425 38
200 lb 483 552 51
350 lb 483 552 51
600 lb (old style) 752 832 64
600 lb (new style) 838 914 76
900 lb 838 914 76
Dimensions A and B must be maintained in order to
obtain a smooth radius in flexible loop.
