Kidde Fire Systems ECS

Parts List
06-236115-001 7-1 October 2014
CHAPTER 7
PARTS LIST
7-1 INTRODUCTION AND PARTS LIST
The table below, and on the following pages, provides a complete list of the Kidde Fire Systems
ECS Fire Suppression System with HFC-227ea Agent parts and associated system equipment.
Equipment can be ordered as complete assemblies or as individual items. In most situations,
when ordering a system, it will be easier and more cost effective to order by assembly part
numbers.
Note: Unless otherwise noted, the parts documented in this section are UL Listed and FM Ap-
proved. For non-agency approved parts, see datasheet K-90-2075.
Table 7-1. Parts List
Nomenclature Part Number Original P/N
Cylinder/Valve Assemblies
10 lb STD 90-100010-001
20 lb STD 90-100020-001
40 lb STD 90-100040-001
70 lb STD 90-100070-001
125 lb STD 90-100125-001
125 lb W/LLI 90-100121-001
200 lb STD Old Style Hemispherical Head before 3/98 90-100200-001
200 lb W/LLI Old Style Hemispherical Head before 3/98 90-100201-001
200 lb STD New Style Ellipsoidal Head after 3/98 90-100200-101
200 lb W/LLI New Style Ellipsoidal Head after 3/98 90-100201-101
350 lb STD 90-100350-001
350 lb W/LLI 90-100351-001
600 lb STD old style supplied before 9/01 (discontinued) 90-100600-001
600 lb W/LLI old style supplied before 9/01 (discontinued) 90-100601-001
600 lb STD new style supplied after 9/01 90-100600-100
600 lb W/LLI new style supplied after 9/01 90-100601-100
900 lb STD 90-100900-001
900 lb W/LLI 90-100901-001
(STD=Standard Cylinder Assembly, W/LLI=Cylinder with liquid level indicator)
Flexible Discharge Hoses
10-125 lb Cylinders WK-283898-000 283898
200-350 lb Cylinders WK-283899-000 283899
600 lb Cylinders (old style supplied before 9/01) WK-283900-000 283900
600 lb Cylinders (new style after 9/01) 06-118225-001
900 lb Cylinders 06-118225-001
