Parts List
06-236115-001 7-3 October 2014
Nomenclature Part Number Original P/N
Pressure Control Equipment
Master Cylinder Adapter Kit 82-844895-000 844895
Male Branch Tee, 5/16 in Flare x 1/8 in NPT WK-699205-050 6992-0505
Male Elbow, 5/16 in Flare x 1/8 in NPT WK-699205-030 6992-0503
Male Connector, 5/16 in Flare x 1/8 in NPT WK-699205-010 6992-0501
Actuation Hose, 22 in (10-200 lb cylinder) WK-264987-000 264987
Actuation Hose, 30 in (350-600 lb cylinder) WK-264986-000 264986
Nitrogen Pilot Cylinder WK-877940-000 877940
Mounting Bracket, N
2
Pilot Cylinder WK-877845-000 877845
1/4 in Check Valve WK-264985-000 264985
Safety Outlet, 3/4 in NPT 82-844346-000 844346
Safety Outlet, 3/4 in NPT 2400-2800 psi (165-193 bars) 81-803242-000 803242
Remote Control Equipment, Electronic Operated
Pull Box, Electric Remote 24 Vdc 84-330001-001 893607
Remote Control Equipment, Cable Operated
Pull Box, Break Glass 81-871403-000 871403
Corner Pulley, Watertight 81-803808-000 803808
Corner Pulley, 1/2 in EMT WK-844648-000
1/16 in Cable 100 ft Roll 06-118316-100 1593-0002
1/16 in Cable 500 ft Roll WK-219649-000 1593-0002
Pull Box Bracket (Z-Bracket) 81-605320-000 60532
Adapter, 1/2 in EMT WK-843837-000 843837
Dual Pull Equalizer 81-840051-000 840051
Dual Pull Mechanism 81-840058-000 840058
Auxiliary Equipment
Supervisory Pressure Switch 06-118262-001
Supervisory Pressure Switch (600-900 lb cylinders manufactured prior
to XXX 2013)
06-118263-001
Pressure Operated Switch, Standard 81-486536-000 486536
Pressure Operated Switch, Ex-Proof 81-981332-000 981332
Pressure Trip 81-874290-000 874290
Transfer Switch, Main to Reserve 84-802398-000 802398
Discharge Indicator 1/2 in (Al) 81-875553-000 875553
Discharge Indicator 3/4 in (Brass) 81-967082-000 967082
Adapter, CO2/N2 Recharge or Agent Valve Seating WK-933537-000 933537
Table 7-1. Parts List
