06-236115-003 5 July 2016

Figure 3. Order of Installation for Electric Control Head, P/N WK-890181-000

Figure 4. Electrical Connections for Control Head, P/Ns WK-890181-000

0.750 NPT TO FLEXIBLE

CONDUIT ADAPTER

PLUS OR HOT CONNECTION

(TERMINAL 3)

TERMINAL STRAP

MICROSWITCH

LEVER

INDICATOR AND

RESET STEM

CAM

SWIVEL

NUT

MINUS, NEUTRAL

OR GROUND CONNECTION

(TERMINAL 1)

OPTIONAL CONNECTION

FOR MICROSWITCH

(TERMINAL 2)

FLEXIBLE CONDUIT
