KidKraft Cedar Summit DEVONSHIRE ELITE - Page 53

53
B
C
B
C
Hardware
6 x #7 x 5/8” Pan Screw
S37
S37
S37
E: In the opening for the door put Dutch Door Assembly in place, measuring to ensure that it is 5/8” (15.9mm) up
from the bottom frame (g. 19.6). Attach hinges to the Front Wall Frame using 3 (S37) #7 x 5/8” Pan Screws per
hinge as shown in g. 19.4 and 19.5.
Step 19: Dutch Door Assembly
Part 2
Fig. 19.4
Fig. 19.5
Fig. 19.6
5/8”
15.9mm
