54
Hardware
2 x #7 x 1-1/8” Pan Screw
S38
S38
Flush
1913
1 x Door Latch Block 15/16 x 2-1/2 x 5”
1913
Wood Parts
F: In the notched out opening of (1913) Door Latch Block attach the Magnetic Catch using 2 (S38) #7 x 1-1/8”
Pan Screws. (g. 19.7) Important: Use a hand held screw driver and DO NOT over tighten.
Step 19: Dutch Door Assembly
Part 3
Fig. 19.7
