M0312-01Model 3605
3-30 07/20
Row Unit Operation
Straight drop in-furrow placement
4½" (115 mm) slope-
compensating bander
GRANULAR CHEMICAL BANDING OPTIONS
Granular chemical banding options allow 4½" (115 mm) slope-compensating banding or straight drop in-furrow
placement.
Optional granular chemical bander shield is installed
on underside of wheel arm stop to shield crop residue
from lodging in granular chemical bander.
GRANULAR CHEMICAL BANDER SHIELD
⅜"-16 x 1½" hex
head cap screw
Wheel arm stop
Bander shield
Hardened washer
Granular chemical bander shield installation
