Model 3605M0312-01
07/20 3-11
Row Unit Operation
SPLIT ROW LOCKUPS
Split row lockups are designed to allow the push row units to be locked in the raised position.
Lift lever positioned on push row unit
Push Row Unit Locked In Raised Position Lockup Released For Field Operation
Improper lifting of row units can cause
serious injury. An empty row unit
requires minimum 84 lb (38.1 kg) lift.
Set down pressure springs to minimum,
lower planter to ground, and empty seed
hopper before attempting to lift with this
lever.
CAUTION
