Kinze 3605 - Specifications

Model 3605M0312-01
07/20 1-5
Specifications
Specification Conventional Hoppers
Number of Rows
12R 70 CM Y 16R 70 CM Y
Base Machine (Empty)*
12,780-13,185 lb (5795-5980 kg) 15,730-16,210 lb (7135-7350 kg)
Axle Weight Empty
10,376 lb (4707 kg) 19,903 lb (9028 kg)
Tongue Weight Empty
2,034 lb (923 kg) 3,497 lb (1586 kg)
Transport Height
11' 4" (3.50 m) 11' 4" (3.50 m)
Planting Length
21' 0" (6.40 m) 23' 11" (7.30 m)
Transport Length
34' 5" (10.50 m) 43' 8" (13.30 m)
Planting Width
29' 6" (9.00 m) 38' 5" (11.70 m)
Transport Width
10' 6" (3.20 m) 10' 6" (3.20 m)
Seed Capacity
1.75 bu (62 L)/Hopper (Vacuum);
1.90 bu (67 L)/Hopper (Mechanical)
1.75 bu (62 L)/Hopper (Vacuum);
1.90 bu (67 L)/Hopper (Mechanical)
Transport Tire Size
Four 255 - 70R 22.5 radial load range ‘H’ tubeless rib implement w/o center groove.
Field Tire Size
7.50" x 20" 8 ply rib implement tires w/o center groove.
Field Lift
Two master/two slave rephasing cylinders.
Row Markers
Independently controlled, three stage, low profile, w/disk blade depth bands.
Specification Bulk Fill
Number of Rows
12R 70 CM Y 16R 70 CM Y
Base Machine (Empty)*
14,590-15,242 lb (6615-6915 kg) 15,600-17,048 lb (7075-7730 kg)
Axle Weight Empty
16,021 lb (7267 kg) 21,980 lb (9970 kg)
Tongue Weight Empty
3,139 lb (1424 kg) 3860 lb (1751 kg)
Transport Height
12' 5" (3.80 m) 12' 5" (3.80 m)
Planting Length
21' 0" (6.40 m) 23' 11" (7.30 m)
Transport Length
34' 5" (10.50 m) 43' 8" (13.30 m)
Planting Width
29' 6" (9.00 m) 38' 5" (11.70 m)
Transport Width
10' 6" (3.20 m) 10' 6" (3.20 m)
Seed Capacity
80 bu (2819 L)
Transport Tire Size
Four 255 - 70R 22.5 radial load range ‘H’ tubeless rib implement w/o center groove.
Field Tire Size
7.50" x 20" 8 ply rib implement tires w/o center groove.
Field Lift
Two master/two slave rephasing cylinders.
Row Markers
Independently controlled, three stage, low profile, w/disk blade depth bands.
*Base machine weight depending on how machine is equipped (meters, drives, and hoppers).
TRACTOR HYDRAULIC REQUIREMENTS
Configuration No Optional Pumps Tractor Mounted PTO Pump
Mechanical Meter
1,2
2 SCV 15 gpm (57 L/min)
Vacuum Meter
1,2
3 SCV 30 gpm (113 L/min) 2 SCV 15 gpm (57 L/min)
Bulk Fill (with Mechanical Meter)
3
3 SCV 25 gpm (95 L/min) 2 SCV 15 gpm (57 L/min)
Bulk Fill (with Vacuum)
2
4 SCV 40 gmp (151 L/min) 3 SCV 25 gpm (95 L/min)
1
Blue drive adds 1 SCV + 10 gpm (38 L/min) (vacuum) min. to requirements.
2
Wing down pressure option adds 1 SCV to conventional only.
3
Blue Drive not available for mechanical planters.
