Model 3605M0312-01
07/20 6-3
Lubrication and MaintenanceLubrication and Maintenance
Inner Wheel Module Drive Chains
Dry Fertilizer Drive Chains
BUSHINGS
Lubricate bushings at frequency indicated.
Check each bolt for proper torque. If bolt is loose, removed it and inspect bushing for cracks and wear. Replace
bushing if necessary. Use only hardened flat washers. Replace damaged flat washers with proper part. Torque
hardware to 176 Nm.
Pull Row Unit and/or Push Row Unit Parallel
Linkages (8 per row)
Row Unit “V” Closing Wheel and/or drag clos-
ing wheel eccentric bushings (2 per row)
