Model 3605M0312-01
07/20 2-37
Machine Operation
BULK FILL SCALE PACKAGE OPTION
• Provides seed weight or estimated acres remaining for each bulk fill hopper.
• Displays total (gross) seed weight or estimated acres remaining for both hoppers combined.
• Warns operator when seed goes below a pre-defined level (when using a Kinze Vision display).
Operation of bulk fill scale package display is controlled by
buttons located on its face:
• Two screen-defined selection buttons.
• Backlight ON/OFF button.
• UP/DOWN arrow buttons.
• Screen position is changed by loosening thumb screw on
mount at back of monitor and repositioning screen.
Screen defined
selection buttons
Backlight ON/
OFF button
UP/DOWN arrow buttons
High-pressure water can damage display.
Remove display before power washing
planter.
NOTICE
Remove and store display at end of
planting season. Damage from sun and
weather exposure may result.
NOTICE
