HYDRAULIC HOSE INFORMATION
Part Number
A1018 A1076 A1110 A1139 A12090 A1424
Description
Hose Assembly
" x 1.02 m (40")
(08F - 08F)
Hose Assembly
" x 3.30 m (130")
(08F - 08F)
Hose Assembly
¼" x 3.81 m (150")
(06F - 06F)
Hose Assembly
¼" x 1.02 m (40")
(06F - 06F)
Hose Assembly
" x 1.60 m (63")
(08F - 08F)
Hose Assembly
½" x 0.76 m (30")
(10F - 10F)
Product
Category
Hydraulic Hose Hydraulic Hose Hydraulic Hose Hydraulic Hose Hydraulic Hose Hydraulic Hose
Product Form
Hose; Assembly Hose; Assembly Hose; Assembly Hose; Assembly Hose; Assembly Hose; Assembly
I.D.
" (9.5 mm) " (9.5 mm) ¼" (6.4 mm) ¼" (6.4 mm) " (9.5 mm) ½" (12.7 mm)
O.D.
/" (17.5 mm) /" (17.5 mm) /" (13.5 mm) /" (13.5 mm) /" (17.5 mm) /" (20.3 mm)
Minimum Bend
Radius
2.5" (64 mm) 2.5" (64 mm) 2" (51 mm) 4" (102 mm) 2.5" (64 mm) 3.5" (89 mm)
Working
Pressure
3000 PSI
(20700 kPa)
3000 PSI
(20700 kPa)
3250 PSI
(22400 kPa)
3275 PSI
(22600 kPa)
3000 PSI
(20700 kPa)
3000 PSI
(20700 kPa)
Temperature
Range
-40°C - +100°C -40°C - +100°C -40°C - +100°C -40°C - +100°C -40°C - +100°C -40°C - +100°C
Material
Modified Nitrile
Type C2
Modified Nitrile
Type C2
Modified Nitrile
Type C2
Modified Nitrile
Type C2
Modified Nitrile
Type C2
Modified Nitrile
Type C2
Specialized
Construction
Single Wire
Braid
Single Wire
Braid
Single Wire
Braid
Single Wire
Braid
Single Wire
Braid
Single Wire
Braid
Media
Hydraulic Fluid Hydraulic Fluid Hydraulic Fluid Hydraulic Fluid Hydraulic Fluid Hydraulic Fluid
Application
Agricultural and
Construction
Agricultural and
Construction
Agricultural and
Construction
Agricultural and
Construction
Agricultural and
Construction
Agricultural and
Construction
Part Number
A1478 A3111 A3131 A3158 A1034 A1053
Description
Hose Assembly
½" x 3.25 m (128")
(10F - 10F)
Hose Assembly
" x 5.08 m (200")
(08F - 08F)
Hose Assembly
" x 1.07 m (42")
(08F - 08F)
Hose Assembly
" x 1.17 m (46")
(08F - 08F)
Hose Assembly
" x 6.91 m (272")
(08F - 08F)
Hose Assembly
" x 1.83 m (72")
(08F - 08F)
Product
Category
Hydraulic Hose Hydraulic Hose Hydraulic Hose Hydraulic Hose Hydraulic Hose Hydraulic Hose
Product Form
Hose; Assembly Hose; Assembly Hose; Assembly Hose; Assembly Hose; Assembly Hose; Assembly
I.D.
½" (12.7 mm) " (9.5 mm) " (9.5 mm) " (9.5 mm) " (9.5 mm) " (9.5 mm)
O.D.
/" (20.6 mm) /" (17.5 mm) /" (17.5 mm) /" (17.5 mm) /" (17.5 mm) /" (17.5 mm)
Minimum Bend
Radius
3.5" (89 mm) 2.5" (64 mm) 2.5" (64 mm) 2.5" (64 mm) 2.5" (64 mm) 2.5" (64 mm)
Working
Pressure
3000 PSI
(20700 kPa)
3000 PSI
(20700 kPa)
3000 PSI
(20700 kPa)
3000 PSI
(20700 kPa)
3000 PSI
(20700 kPa)
3000 PSI
(20700 kPa)
Temperature
Range
-40°C - +100°C -40°C - +100°C -40°C - +100°C -40°C - +100°C -40°C - +100°C -40°C - +100°C
Material
Modified Nitrile
Type C2
Modified Nitrile
Type C2
Modified Nitrile
Type C2
Modified Nitrile
Type C2
Modified Nitrile
Type C2
Modified Nitrile
Type C2
Specialized
Construction
Single Wire
Braid
Single Wire
Braid
Single Wire
Braid
Single Wire
Braid
Single Wire
Braid
Single Wire
Braid
Media
Hydraulic Fluid Hydraulic Fluid Hydraulic Fluid Hydraulic Fluid Hydraulic Fluid Hydraulic Fluid
Application
Agricultural;
Construction
Agricultural;
Construction
Agricultural;
Construction
Agricultural;
Construction
Agricultural;
Construction
Agricultural;
Construction
