Model 3605M0312-01
07/20 2-11
Machine Operation
CYLINDER INFORMATION (Continued)
Center Lift Cylinder Wing Lock Cylinder
Transport Latch
Cylinder
Tongue Lock
Cylinder
Intended Use
Double acting
applications
Double acting
applications
Double acting
applications
Double acting
applications
Piston
Ductile iron Ductile iron Ductile iron Ductile iron
Gland
Ductile iron Ductile iron Ductile iron Ductile iron
Tube
ST 52 Dom ST 52 Dom Cast Cast
Rod
1045 Nitro rod 1045 Nitro rod 1045 Nitro rod 1045 Nitro rod
End Mounts
Gimble Sleeve None None
Tube Seal
Buna O-Ring with
polytemp back-up
O-Ring with
polytemp back-up
O-Ring with
polytemp back-up
O-Ring with
polytemp back-up
Rod Seal
Polyester alloy u-cup Polyester alloy u-cup Polyester alloy u-cup Polyester alloy u-cup
Rod Wiper
Polyester alloy snap
in
Polyester alloy snap
in
Polyester alloy snap
in
Polyester alloy snap
in
Piston Seal
PTFE T-Seal HNBR T-Seal HNBR T-Seal HNBR
Specifications
Product
Category
Hydraulic Cylinder Hydraulic Cylinder Hydraulic Cylinder Hydraulic Cylinder
Maximum
Stroke
48" (1219 mm) 20.062" (510 mm) 2.5" (64 mm) 2.5" (64 mm)
Working
Pressure
3000 PSI
(20700 kPa)
3000 PSI
(20700 kPa)
3000 PSI
(20700 kPa)
3000 PSI
(20700 kPa)
Bore Size
3.25" (83 mm) 2.5" (64 mm) 1.5" (38 mm) 1.5" (38 mm)
Shaft
Diameter
2" (51 mm) 1.5" (38 mm) .750" (19 mm) .750" (19 mm)
Cylinder
Configuration
Simple Simple Simple Simple
Cylinder
Action
Double Double Double Double
Material
Steel, Ductile Iron Steel, Ductile Iron
Steel, Ductile Iron,
Cast
Steel, Ductile Iron,
Cast
Mounting
Method
Gimble Sleeve None None
Mount
Location
Side's of Barrel End Cap End Cap End Cap
Cylinder
Style
Welded Welded Machined Machined
