Model 3605M0312-01
07/20 2-1
Machine Operation
MANUAL SAFETY LOCKUP
Always install row marker lockups when working or
transporting planter.
Connect chain between marker stand and second
stage of marker assembly.
Remove manual safety lockup and store on L.H. side of hitch for field operation.
Manual safety lockup in transport positionManual safety lockup in storage position
ROW MARKER SAFETY LOCKUP
Row marker safety lockup installed
Uncontrolled machine movement can
crush or cause loss of control resulting
in death, serious injury, or damage to
property and equipment. Install all safety
lockup devices before working under or
transporting this equipment.
WARNING
Row marker can lower at any time and
could cause death or serious injury. Stay
away from row markers! Install safety
lockup device when not in use.
WARNING
