HYDRAULIC HOSE INFORMATION (Continued)
Part Number
A1116 A12042 A1404 A11443 A11442 A3122
Description
Hose Assembly
¼" x 3.45 m (136")
(06F - 06F)
Hose Assembly
" x 5.79 m (228")
(08F - 08F)
Hose Assembly,
½" x 1.04 m (41")
(10F - 10F)
Hose Assembly,
" x ~185 cm
(73") (12F - 12F)
Hose Assembly,
" x ~349 cm
(137.5") (12F -
12F)
Hose Assembly,
" x 0.27 m (10½")
(08F - 08F)
Product
Category
Hydraulic Hose Hydraulic Hose Hydraulic Hose Hydraulic Hose Hydraulic Hose Hydraulic Hose
Product Form
Hose; Assembly Hose; Assembly Hose; Assembly Hose:Assembly Hose:Assembly Hose; Assembly
I.D.
¼" (6.0 mm) " (9.5 mm) ½" (13.0 mm)
5
/
8
" (~15,88 mm)
5
/
8
" (~15,88 mm) " (9.5 mm)
O.D.
/" (13.5 mm) /" (17.5 mm) /" (20.6 mm) ⁄" (~23,81 mm) ⁄" (~23,81 mm) /" (17.5 mm)
Minimum Bend
Radius
4" (102 mm) 2.5" (64 mm) 3.5" (89 mm)
4"
(~101,60 mm)
4"
(~101,60 mm)
2.5" (64 mm)
Working
Pressure
3275 PSI
(22600 kPa)
3000 PSI
(20700 kPa)
3000 PSI
(20700 kPa)
2750 PSI
(~18961 kPa)
2750 PSI
(~18961 kPa)
3000 PSI
(20700 kPa)
Temperature
Range
-40°C - +100°C -40°C - +100°C -40°C - +100°C -40°C - +100°C -40°C - +100°C -40°C - +100°C
Material
Modified Nitrile
Type C2
Modified Nitrile
Type C2
Modified Nitrile
Type C2
Modified Nitrile
Type C2
Modified Nitrile
Type C2
Modified Nitrile
Type C2
Specialized
Construction
Single Wire
Braid
Single Wire
Braid
Single Wire
Braid
High tensile steel
wire
High tensile steel
wire
Single Wire
Braid
Media
Hydraulic Fluid Hydraulic Fluid Hydraulic Fluid Hydraulic Fluid Hydraulic Fluid Hydraulic Fluid
Application
Agricultural;
Construction
Agricultural;
Construction
Agricultural;
Construction
Agricultural;
Construction
Agricultural;
Construction
Agricultural;
Construction
Part Number
A3139 A8267 A1055 A11449 A11450 A12754
Description
Hose Assembly,
" x 6.45 m (254")
(08F - 08F)
Hose Assembly,
½" x 1.47 m (58")
(10F - 10F)
Hose Assembly,
" x 1.68 m (66")
(08F - 08F)
Hose Assembly,
" x ~523 cm
(206") (1/2M
NPTF - 12F)
Hose Assembly,
" x ~676 cm
(266") (1/2M
NPTF - 12F)
Hose Assembly
½" x ~523 cm
(206")
(1/2M NPTF -
10F)
Product
Category
Hydraulic Hose Hydraulic Hose Hydraulic Hose Hydraulic Hose Hydraulic Hose Hydraulic Hose
Product Form
Hose; Assembly Hose; Assembly Hose; Assembly Hose:Assembly Hose:Assembly Hose; Assembly
I.D.
" (9.5 mm) ½" (13.0 mm) " (9.5 mm)
5
/
8
" (~15,88 mm)
5
/
8
" (~15,88 mm) ½" (12.7 mm)
O.D.
/" (17.5 mm) /" (20.6 mm) /" (17.5 mm) ⁄" (~23,81 mm) ⁄" (~23,81 mm) /" (20.6 mm)
Minimum Bend
Radius
2.5" (64 mm) 3.5" (89 mm) 2.5" (64 mm)
4"
(~101,60 mm)
4"
(~101,60 mm)
3.5" (89 mm)
Working
Pressure
3000 PSI
(20700 kPa)
3000 PSI
(20700 kPa)
3000 PSI
(20700 kPa)
2750 PSI
(~18961 kPa)
2750 PSI
(~18961 kPa)
3000 PSI
(20700 kPa)
Temperature
Range
-40°C - +100°C -40°C - +100°C -40°C - +100°C -40°C - +100°C -40°C - +100°C -40°C - +100°C
Material
Modified Nitrile
Type C2
Modified Nitrile
Type C2
Modified Nitrile
Type C2
Modified Nitrile
Type C2
Modified Nitrile
Type C2
Modified Nitrile
Type C2
Specialized
Construction
Single Wire
Braid
Single Wire
Braid
High tensile
steel wire
High tensile steel
wire
High tensile steel
wire
Single Wire
Braid
Media
Hydraulic Fluid Hydraulic Fluid Hydraulic Fluid Hydraulic Fluid Hydraulic Fluid Hydraulic Fluid
Application
Agricultural;
Construction
Agricultural;
Construction
Agricultural;
Construction
Agricultural;
Construction
Agricultural;
Construction
Agricultural;
Construction
