Kinze 3605 - Page 32

M0312-01Model 3605
2-14 07/20
Machine Operation
HYDRAULIC HOSE INFORMATION (Continued)
Part Number
A8266 A12751 A1464 A3117 A12076 A12085
Description
Hose Assembly
½" x ~681 cm
(268")
(10F - 10F)
Hose Assembly
½" x ~362 cm
(142.5")
(10F - 10F)
Hose Assembly
½" x ~183 cm
(72")
(10F - 10F)
Hose Assembly
" x ~447 cm
(176")
(08F - 08F)
Hose Assembly
" x ~419 cm
(165")
(08F - 08F)
Hose Assembly
" x ~66 cm
(26")
(08F - 10F)
Product
Category
Hydraulic Hose Hydraulic Hose Hydraulic Hose Hydraulic Hose Hydraulic Hose Hydraulic Hose
Product Form
Hose; Assembly Hose; Assembly Hose; Assembly Hose; Assembly Hose; Assembly Hose; Assembly
I.D.
½" (12.7 mm) ½" (12.7 mm) ½" (12.7 mm) " (9.5 mm) " (9.5 mm) " (9.5 mm)
O.D.
/" (20.6 mm) /" (20.6 mm) /" (20.6 mm) /" (17.5 mm) /" (17.5 mm) /" (17.5 mm)
Minimum Bend
Radius
3.5" (89 mm) 3.5" (89 mm) 3.5" (89 mm) 2.5" (64 mm) 2.5" (64 mm) 2.5" (64 mm)
Working
Pressure
3000 PSI
(20700 kPa)
3000 PSI
(20700 kPa)
3000 PSI
(20700 kPa)
3000 PSI
(20700 kPa)
3000 PSI
(20700 kPa)
3000 PSI
(20700 kPa)
Temperature
Range
-40°C - +100°C -40°C - +100°C -40°C - +100°C -40°C - +100°C -40°C - +100°C -40°C - +100°C
Material
Modified Nitrile
Type C2
Modified Nitrile
Type C2
Modified Nitrile
Type C2
Modified Nitrile
Type C2
Modified Nitrile
Type C2
Modified Nitrile
Type C2
Specialized
Construction
Single Wire
Braid
Single Wire
Braid
Single Wire
Braid
Single Wire
Braid
Single Wire
Braid
Single Wire
Braid
Media
Hydraulic Fluid Hydraulic Fluid Hydraulic Fluid Hydraulic Fluid Hydraulic Fluid Hydraulic Fluid
Application
Agricultural;
Construction
Agricultural;
Construction
Agricultural;
Construction
Agricultural;
Construction
Agricultural;
Construction
Agricultural;
Construction
Part Number
A12752 A1021 A18693- A12747 A18667- A21548-
Description
Hose Assembly
½" x ~58.5 cm
(23")
(10F - 12F)
Hose Assembly
" x ~142 cm
(56")
(08F - 08F)
Hose Assembly
½" x - cm (-")
(10F - 1/2M
NPTF)
Hose Assembly
½" x ~498 cm
(196")
(08F - 10F)
Hose Assembly
½" x - cm (-")
(08F - 08F)
Hose Assembly,
" x - cm
(-") (12F - 1/2M
NPTF)
Product
Category
Hydraulic Hose Hydraulic Hose Hydraulic Hose Hydraulic Hose Hydraulic Hose Hydraulic Hose
Product Form
Hose; Assembly Hose; Assembly Hose; Assembly Hose; Assembly Hose; Assembly Hose:Assembly
I.D.
½" (12.7 mm) " (9.5 mm) ½" (12.7 mm) ½" (12.7 mm) ½" (12.7 mm)
5
/
8
" (~15,88 mm)
O.D.
/" (20.6 mm) /" (17.5 mm) /" (20.6 mm) /" (20.6 mm) /" (20.6 mm) ⁄" (~23,81 mm)
Minimum Bend
Radius
3.5" (89 mm) 2.5" (64 mm) 3.5" (89 mm) 3.5" (89 mm) 3.5" (89 mm)
4"
(~101,60 mm)
Working
Pressure
3000 PSI
(20700 kPa)
3000 PSI
(20700 kPa)
3000 PSI
(20700 kPa)
3000 PSI
(20700 kPa)
3000 PSI
(20700 kPa)
2750 PSI
(~18961 kPa)
Temperature
Range
-40°C - +100°C -40°C - +100°C -40°C - +100°C -40°C - +100°C -40°C - +100°C -40°C - +100°C
Material
Modified Nitrile
Type C2
Modified Nitrile
Type C2
Modified Nitrile
Type C2
Modified Nitrile
Type C2
Modified Nitrile
Type C2
Modified Nitrile
Type C2
Specialized
Construction
Single Wire
Braid
Single Wire
Braid
Single Wire
Braid
Single Wire
Braid
Single Wire
Braid
High tensile steel
wire
Media
Hydraulic Fluid Hydraulic Fluid Hydraulic Fluid Hydraulic Fluid Hydraulic Fluid Hydraulic Fluid
Application
Agricultural;
Construction
Agricultural;
Construction
Agricultural;
Construction
Agricultural;
Construction
Agricultural;
Construction
Agricultural;
Construction
