Kinze 3605 - Page 33

Model 3605M0312-01
07/20 2-15
Machine Operation
HYDRAULIC HOSE INFORMATION (Continued)
Part Number
A25487 A11440 A21530- A12097 A15081- A7678-
Description
Hose Assembly,
" x - cm
(-") (10F - 12F)
Hose Assembly,
" x ~620 cm
(244") (10F -
10F)
Hose Assembly,
" x - cm
(-") (10F - 10F)
Hose Assembly
" x ~625 cm
(246")
(06F - 06F)
Hose Assembly
" x - cm (-")
(06F - 06F)
Hose Assembly
¼" x -cm (-")
(04F - 04F)
Product
Category
Hydraulic Hose Hydraulic Hose Hydraulic Hose Hydraulic Hose Hydraulic Hose Hydraulic Hose
Product Form
Hose:Assembly Hose:Assembly Hose:Assembly Hose; Assembly Hose; Assembly Hose; Assembly
I.D.
5
/
8
" (~15,88 mm)
5
/
8
" (~15,88 mm)
5
/
8
" (~15,88 mm) " (9.5 mm) " (9.5 mm) ¼" (6.4 mm)
O.D.
⁄" (~23,81 mm) ⁄" (~23,81 mm) ⁄" (~23,81 mm) /" (17.5 mm) /" (17.5 mm) /" (13.5 mm)
Minimum Bend
Radius
4"
(~101,60 mm)
4"
(~101,60 mm)
4"
(~101,60 mm)
2.5" (64 mm) 2.5" (64 mm) 2" (51 mm)
Working
Pressure
2750 PSI
(~18961 kPa)
2750 PSI
(~18961 kPa)
2750 PSI
(~18961 kPa)
3000 PSI
(20700 kPa)
3000 PSI
(20700 kPa)
3250 PSI
(22400 kPa)
Temperature
Range
-40°C - +100°C -40°C - +100°C -40°C - +100°C -40°C - +100°C -40°C - +100°C -40°C - +100°C
Material
Modified Nitrile
Type C2
Modified Nitrile
Type C2
Modified Nitrile
Type C2
Modified Nitrile
Type C2
Modified Nitrile
Type C2
Modified Nitrile
Type C2
Specialized
Construction
High tensile steel
wire
High tensile steel
wire
High tensile steel
wire
Single Wire
Braid
Single Wire
Braid
Single Wire
Braid
Media
Hydraulic Fluid Hydraulic Fluid Hydraulic Fluid Hydraulic Fluid Hydraulic Fluid Hydraulic Fluid
Application
Agricultural;
Construction
Agricultural;
Construction
Agricultural;
Construction
Agricultural;
Construction
Agricultural;
Construction
Agricultural and
Construction
Part Number
A7677- A25504- A7680- A12038 A12095 A12755
Description
Hose Assembly
¼" x -cm (-")
(04F - 04FSTD90)
Hose Assembly
" x - cm (-")
(08FS90 - 06F)
Hose Assembly
¼" x -cm (-")
(04F - 06F)
Hose Assembly
" x ~76 cm
(30")
(06F - 06F)
Hose Assembly
" x ~203 cm
(80")
(06F - 06F)
Hose Assembly
½" x ~112 cm
(44")
(10F - 10F)
Product
Category
Hydraulic Hose Hydraulic Hose Hydraulic Hose Hydraulic Hose Hydraulic Hose Hydraulic Hose
Product Form
Hose; Assembly Hose; Assembly Hose; Assembly Hose; Assembly Hose; Assembly Hose; Assembly
I.D.
¼" (6.4 mm) " (9.5 mm) ¼" (6.4 mm) " (9.5 mm) " (9.5 mm) ½" (12.7 mm)
O.D.
/" (13.5 mm) /" (17.5 mm) /" (13.5 mm) /" (17.5 mm) /" (17.5 mm) /" (20.6 mm)
Minimum Bend
Radius
2" (51 mm) 2.5" (64 mm) 2" (51 mm) 2.5" (64 mm) 2.5" (64 mm) 3.5" (89 mm)
Working
Pressure
3250 PSI
(22400 kPa)
3000 PSI
(20700 kPa)
3250 PSI
(22400 kPa)
3000 PSI
(20700 kPa)
3000 PSI
(20700 kPa)
3000 PSI
(20700 kPa)
Temperature
Range
-40°C - +100°C -40°C - +100°C -40°C - +100°C -40°C - +100°C -40°C - +100°C -40°C - +100°C
Material
Modified Nitrile
Type C2
Modified Nitrile
Type C2
Modified Nitrile
Type C2
Modified Nitrile
Type C2
Modified Nitrile
Type C2
Modified Nitrile
Type C2
Specialized
Construction
Single Wire
Braid
Single Wire
Braid
Single Wire
Braid
Single Wire
Braid
Single Wire
Braid
Single Wire
Braid
Media
Hydraulic Fluid Hydraulic Fluid Hydraulic Fluid Hydraulic Fluid Hydraulic Fluid Hydraulic Fluid
Application
Agricultural and
Construction
Agricultural;
Construction
Agricultural and
Construction
Agricultural;
Construction
Agricultural;
Construction
Agricultural;
Construction
