Kinze 3605 - Page 183

Model 3605M0312-01
07/20 6-49
Lubrication and Maintenance
Wire Hookup Chart (Continued)
Reference
Designator
From To Color Function
W5 SW5-2 SW11-2 Red Jumper Wire
W6 SW8-1 SW8-3 Red Jumper Wire
W7 SW1-3 SW2-5 Red Jumper Wire
W8 SW1-1 SW4-2 Red Jumper Wire
W9 SW1-2 TB1 Red Tractor Power
W10 SW8-2 TB1 Red Tractor Power
W11 SW2-4 TB3 Red Marker LED
W12 SW2-6 TB3 Red Marker LED
W13 DS2(+) TB3 Red Marker LED
W14 DS2(-) SW12-5 Black Tractor Ground
W15 SW10-2 TB1 Red Tractor Power
W16 SW11-3 TB4 Blue L VAC Increase
W17 SW11-4 TB4 Blue L VAC Increase
W18 SW11-1 TB5 White/
Blue
L VAC Decrease
W19 SW11-6 TB5 White/
Blue
L VAC Decrease
W20 SW12-3 TB6 Violet R VAC Increase
W21 SW12-4 TB6 Violet R VAC Increase
W22 SW12-1 TB7 White/
Violet
R VAC Decrease
W23 SW12-6 TB7 White/
Violet
R VAC Decrease
W24 SW11-5 TB2 Black Tractor Ground
W25 SW11-5 SW12-5 Black Jumper Wire
U1
Red TB1 Red Tractor Power
Black TB2 Black Tractor Ground
Yellow DS1-1 Yellow Display Light
Orange DS1-2 Orange Display Light
