M0312-01Model 3605
3-8 07/20
Row Unit Operation
True Depth
TRUE DEPTH OPTION
True Depth provides on demand row by row hydraulic row unit down force ranging from ~45 kg. up force to ~270 kg.
down force at 2350 psi. The system includes a 7" in cab standalone touchscreen display with antiglare screen
protector and RAM mount, electronic control modules, harnesses, gauge wheel sensors, hydraulic cylinders, upper
and lower cylinder mounts, and valves. See M0288 - Kinze Blue Vantage Operator’s Manual.
PSI x 4 x 0.45 =
MAX. ~218
PDP Down Force Calculation
To Next Page
