Kinze 3605 - Page 87

Model 3605M0312-01
07/20 3-17
Row Unit Operation
VACUUM SETTINGS
Crop
**Seed
Disc Kit
Seed
Disc
Part No.
Ejector
Wheel
(Color) Cells
Seed Size
Range
Singulator
Zone
Setting
Vacuum
Setting
Inches of
Water (cm) Lubricant
Specialty
Disc 3 G10282XG10282X
B1234B1234
(Dark
Blue)
1 row
6 punches
(Green)
60
Pinto & Great
Northern edible
beans &
low-rate
soybean
2
15-20
(38-51)
Graphite*
Talc as
needed*
Rapeseed G10283XG10283X
B1239
(Dark
Gray)
1 row
10 punches
(Dark Gray)
83
See Rapeseed
Planting
Section
0
See
Rapeseed
Planting
Section
Kinze Brand
Graphite Only
Wheat
disc
G10274XG10274X
B1239 B1239
(Purple)(Purple)
Brush type 54 N/A Volumetric 0
6-16
(15-41)
Graphite*
Talc*
Install selected seed disc. Position vacuum cover on meter by aligning keyhole slots over bolt heads. Push cover on meter and
turn counter clockwise to lock in place.
*For More information on application rate, see Additives section.
**Includes seed disc, ejector wheel, and spring.
