SERVICE MANUAL
24 11NOV05 – SM7648-1
[41] Check each of the options on the MODE DIAL.
FOCUS 1. Press:
•“FOCUS BUTTON
JOYSTICK down to set the mode to Macro AF
OK BUTTON
2. Check that the Flower icon displays on the MONITOR LCD.
3. Press:
•“FOCUS BUTTON
JOYSTICK down to set the mode to Landscape
OK BUTTON
4. Check that the Mountain icon displays on the MONITOR LCD.
5. Press:
•“FOCUS BUTTON
JOYSTICK up to set the mode to Manual
OK BUTTON
6. Check that the 0 -
icon displays.
7. Move the JOYSTICK left and right to see the focus window.
8. Press:
•“FOCUS BUTTON
JOYSTICK down to set the mode to Normal AF
OK BUTTON
9. The options should not be displayed and the focus is returned to automatic.
EVF/LCD 1. Press the EVF/LCD BUTTON.
2. Check that the view is through the VIEWFINDER AY.
3. Press the EVF/LCD BUTTON again.
4. Check that the view is displayed on the MONITOR LCD.
MODE DIAL The MODE DIAL has 10 options.
Selected MODE DIAL
Option Do:
AUTO 1. Move the MODE DIAL to AUTO.
2. Check that Auto: displays on the MONITOR LCD.
3. Press the SHUTTER BUTTON to the S1 position.
4. Check that the following information displays on the MONITOR LCD:
aperture setting
SHUTTER speed
P, A, S, M, C1,
C2, C3
1. Move the MODE DIAL to each option.
2. Check that the corresponding option name displays on the MONITOR LCD.
3. Use the COMMAND DIAL to select the icons of the settings.
4. Select an icon and press the SET BUTTON.
5. Check:
icon changes color
COMMAND DIAL changes the setting
BUTTON/SWITCH Do:
