CVS-842/852/843 Chapter 2
Operation Manual Equipment Composition
Chapter 2 Equipment Composition
2.1 Standard equipment list
No Item name Type name Remarks Weight/Length Q’ty
CVS-842 With base mount ,Cover 6.5 kg
CVS-852 With base mount ,Cover 10.0 kg
1 Display Unit
CVS-843 With base mount
,Cover 6.5 kg
1
2 DC cable CW-253-2M For Display Unit 2m 1
3 TX/RX Unit
CVT-10
6.0 kg 1
4 DC cable CW-89-3M For TX/RX Unit 3m 1
5 Connecting
Cable
CW-557-5M For Display and TX/RX
Unit
5m 1
6 Spare parts Detail in Spare Parts
List
1 set
7 Installation
material
Detail in Installation
Material List
1 set
8 Operation
manual
English 1 set
2.2 Spare parts list
No. Item name Type name Remarks Weight/Length Q’ty
1 Fuse F-7161-5A
/N30C-125V
For Display Unit 2
2
Fuse ﾞ
F-7161-10A
/N30C-125V
For TX/RX Unit 2
2.3 Installation materials list
No. Item name Type name Remarks Weight/Length Q’ty
1 Crimping terminal V2-4-1 blue
For Transducer connections
6
2.4 Available transducers list
Output Type name Frequency Weight
TD-282 28 kHz 7.0 kg
TD-501B 50 kHz 4.2 kg
TD-751 75 kHz 4.2 kg
1 kW
TD-2001D 200 kHz 4.2 kg
TD-284 28 kHz 11.0 kg
TD-504T 50 kHz 11.0 kg
TD-754 75 kHz 6.5 kg
3 kW
TD-66 (See NOTE) 200 kHz 4.2 kg
TD-286F 28 kHz 15.4 kg
TD-506F 50 kHz 13.0 kg
TD-756 75 kHz 11.0 kg
5 kW
TD-66 (See NOTE) 200 kHz 4.2 kg
NOTE: The effective power output available from the 200 KHz transducers specified to 3 kW/5kW
is 1 kW.
93132692-00 2-1
