2.5 Optional Items list
No. Item name Type name Remarks Weight/Length
ST-80-1
Transom (Plastic,cablefitted) 0.3Kg
ST-90-1
Through hull (Plastic, cable fitted) 0.6Kg
1 Temperature/
speed sensor
ST-100-1
Through hull (Bronze, cable fitted)
1.2Kg
J7-101
Single frequency 1.6kg
2 TD Switch
J8-201
Dual frequency 2.2kg
3 Inner hull kit
MFB-04W
Plastic, applicable for 1KW only 1.5kg
4 Kingston kit MFB-05W Applicable for 1KW only 0.83kg
5 Junction Box for
TD connections
JB-32
For dual frequency 2.0kg
JB-10 1 input, 3 outputs × 2 circuits 0.4kg 6 Junction Box
for Navigator
unit connection
JB-12
1 input, 3 outputs, 3 inputs,
1 output
0.42kg
7 AC/DC Rectifier PS-006 With 2 pcs of 10A fuse attached 8.0kg
8 AC Power cable
VV-2D8-3M
Both ends fly leads (For power
supply)
3m
9 Extension
cable
VSV-2T11-3M
red/white
Both ends fly leads
(For Transducer)
3m
10 Earthing lead OW7/1.6S-3M 3m
CW-371-5M
5P connector
/5P waterproof connector (LTW)
5m
11 Connecting
cable (For
external
sounder)
CW-372-5M Fly leads/5P waterproof connector
(LTW)
5m
CW-373-5M
6P waterproof connector both
ends (LTW)
5m
CW-374-5M
6P connector/6P waterproof
connector (LTW)
5m
CW-375-5M
6P waterproof connector (Conxall)
/6P waterproof connector (LTW)
5m
12 Connecting
cable (For
navigator unit)
CW-376-5M
Fly leads
/6P waterproof connector (LTW)
5m
CW-60-10M
BNC/Crimp terminal 10m
CW-154A-5M 6P Connector/Fly leads 5m
CW-352-5M 6P waterproof connector
(Conxall)/Crimp terminals
5m
13 Connecting
cable (For
Navigator Unit
and Junction
Box)
CW-328-5M
6P waterproof connector (Conxall) /
Crimp terminals
5m
LTWBD-05BFFA
-L180
5P waterproof connector (LTW)
for external sounder
LTWBD-06BFFA
-L180
6P waterproof connector (Conxall)
for NMEA0183
14 Connector
female
LTWBD-08BFFA
-L180
8P waterproof connector (LTW)
for 8water/temperature sensor
CG-1
For steel hull, single frequency 1.5Kg
CG-2
For steel hull, dual frequency 1.5Kg
CG-3
For wooden hull, single frequency 2.5Kg
CG-4 For wooden hull, dual frequency 3.5Kg
CG-16
For FRP hull, single frequency 0.9Kg
CG-18 For FRP hull, dual frequency 1.8Kg
15 Cable gland
CG-19
For wooden/FRP hull, single frequency 1.0Kg
