CVS-842/852/843 Chapter 7
Operation Manual Functional Registration
93132692-00 7-1
Chapter 7 Functional Registration
This chapter describes the procedures to register the user defined functional parameters to the Range
and MODE switches. The items that can be registered are as follows:
(1) Depth ranges
(2) Display modes (USER 1 , USER 2 , USER 3 and Zoom)
7.1 Depth range registration
This procedure is used to register the sounding depth to each range number shown on the operating
panel around the range selection switch. To register:
(1) Press the MENU key to display the main menu.
(2) Press the up or down arrow key to highlight SYSTEM
and press the right key to show the SYSTEM sub menu.
(3) Press the up or down key to highlight DEPTH RANGE PRESET and press the right arrow key to
show the range registration list.
(4) Press the up or down arrow key to select the range number.
(5) Press the right arrow key to show the range number window.
Menu
Transmission
Display
Auto
System
Customize
Initialize
Simulator
Range numbe
r
Sounding range
2
1
Depth Range Preset
3
4
5
6
7
8
20
50
80
100
120
150
200
5
System
Time
Depth Unit m
Depth Range Preset
Draft Setting 0.0
Bottom Start 5.0
B
o
tt
om
D
e
t
ec
ti
on
Adjust
Bottom Detection
Sonic Correction 0%
Water Temp
Correction
Boat Speed
Correction
I
ns
id
e
Range
0.0
0.0
Depth Measurement Auto
Figure 7.1 Depth range registration (1)
System
Time
Depth Unit m
Depth Range Preset
Draft Setting 0.0
Bottom Start 5.0
B
o
tt
om
D
e
t
ec
ti
on
Adjust
Bottom Detection
Sonic Correction 0%
Water Temp
Correction
Boat Speed
Correction
I
ns
id
e
Range
0.0
0.0
Depth Measurement Auto
