MDC-2200/2500 Series Chapter 2 Function and control names
0093125002-02 2-5
21 [F3] function key Note: This function is not available for MDC-2200.
This key is used for function key. Function assignment is selected in startup menu.
22 [PANEL] key Note: Panel dimmer is changed over by [BRILL] key for MDC-2200.
This key is used to change panel dimmer.
23 [PI] lamp Note: This function is not available for MDC-2200.
This lamp is on during parallel index line function is selected.
24 [VRM] knob Note: [EBL] / [VRM] knobs are common for MDC-2200.
This knob is used to operate VRM or to adjust panel dimmer.
25 [SP/LP] key
This key is used to change pulse length to improve target delectability.
26 [OFF CENT] key
This key is used to switch on or off Off center.
27 [MODE] key Note: This function is not available for MDC-2200.
This key is used to switch over display mode such as Head-up, North-up etc.
28 [OFF] key
Heading line is erased during this key is pressed.
Alarm sound is stopped by pressing this key at the time when alarm is sounding.
Deleting operation is performed by using this key in combination with other keys.
29 [Joy stick]
This device is used for cross cursor operation, menu operation, target acquisition operation
or mark input operation.
