Koden MDC2260 - CHART menu

MDC-2200/2500 Series Chapter 4 Menu operations
0093125002-05 4-33
4.8 CHART menu
Following items are provided in Chart menu.
Note: (1) CHART, (16) CHART DISP SET is not displayed without Chart card.
CHART
PAST CRS
SETUP
PLOT INT
CLEAR
WPT/ROUTE
MARK
BLOCK NO
BLOCK CLEAR
LINE
SHAPE
OWN
CURSOR
SETUP
DISP ALL
CHART SELECT
CHART DISP SET
NAV ALIGN MODE
NAV ALIGN LAT
NAV ALIGN LON
WPT/ROUTE ID
WPT FLAG
COAST LINE/GPS BUOY
COAST LINE
GPS BUOY
Shaded display is displayed in detailed Menu.
(1)
(2)
(3)
(4)
(5)
(6)
(7)
(8)
(9)
(10)
(11)
(12)
(13)
(14)
(15)
(16)
(17)
(18)
(19)
(20)
(21)
(22)
(23)
(24)
OFF / ON
1 - 30 (OFF / DISP / OWN / ATA / AIS)
OFF / CONTINUE / 15SEC / 30SEC / 1MIN / 3MIN / 6MIN / 12MIN
1 - 30 (CANCEL / CLEAR)
OFF / ON
OFF / ON
1 - 20
CANCEL / CLEAR
OFF / ON
(Select mark shape from 18 types)
(Input mark on own ship position)
(Input mark on cursor position)
(Input mark by latitude/longitude)
OFF / ON
JAPAN / GLOBAL
(Chart setting: color, place name, lighthouse, buoy, etc.)
OFF / MANUAL / SERIAL
-1.000 - 1.000
-1.000 - 1.000
OFF / ON
OFF / ON
Coast line/GPS buoy
(Enable to produce coast line by itself)
(Enable to display GPS buoys)
