Chapter 4 Menu operations MDC-2200/2500 Series
0093125002-05 4-10
4.3 ECHO menu
Following setting items are provided for Echo menu.
MODE
TRAILS*
MODE
COLOR
SHAPE
RANGE KEEP
TIME KEEP*
TRUE MOVE
REL MODE
DETECT LVL
IR
PROCESS
DAY/NIGHT
ECHO COLOR D
ECHO COLOR N
BACK COLOR D
BACK COLOR N
ZOOM
TM RESET
TM RESET POSI
HOLD
SECTOR
RANGE UNIT
ROTATION MARGIN
ROTATION SPEED
ALL PPI
OFF CENT POSI
Shaded item is displayed in detailed menu.
(1)
(2)
(3)
(4)
(5)
(6)
(7)
(8)
(9)
(10)
(11)
(12)
(13)
(14)
(15)
(16)
(17)
(18)
(19)
(20)
(21)
(22)
(23)
(24)
(25)
(26)
(27)
H UP
RM
/ C UP
RM
/ C UP
TM
/ N UP
RM
/ N UP
TM
OFF / CONTINUE / 30SEC / 1MIN / 3MIN / 6MIN / 12MIN / 24MIN / 48MIN
TRUE / REL
BLUE / RED
OFF / ON
OFF / ON
COURSE / POSITION
HDG / TRUE
1 - 6
OFF / 1 / 2 / 3 / 4 / 5
OFF / 1 / 2 / 3
DAY / NIGHT
WHITE / YELLOW / GREEN / MULTI
WHITE / YELLOW / GREEN / MULTI
Action
Action
OPPOSITE / COURSE / CENTER
OFF / 1 / 2 START ANGLE, END ANGLE
NM / km / sm
0 - 30°
1 - 50
OFF / ON
CURSOR / OPPOSITE
* When TIME KEEP is ON, selectable time of TRAILS menu are:
OFF, CONTINUE, 30s, 1min, 3min, 6min, 12min, 24min, 48min,
1hr, 2hr, 4hr, 8hr, 16hr, 24hr
