MDC-2200/2500 Series Chapter 4 Menu operations
0093125002-05 4-41
NUM DISP
WAT TEMP DISP
BLOCK NUMBER
BLOCK CLEAR
BLOCK DATA
TIME
NUMBER
LAT
LON
CRS
SPD
WAT TEMP
BATT VOL
ON
ON
1
>
>
11/25 16:33:40
1
39°13.600N
139°46.000E
0.0°
5kn
-9.8°C
12.3V
1
2
3
4
5
6
1. NUM DISP
This is the function to display Buoy IDs at the right sides of the latest data buoy symbols
2. WAT TEMP DISP
This is the function to display water temperature under the buoy symbols.
3. BLOCK NUMBER
This is the function to select block numbers. 1 ID buoy data can be recorded in 1 block.
The following 4 ~ 6 will be applied to the blocks selected in above 3.
4. BLOCK CLEAR
This is the function to deleted buoy data recorded in blocks.
5. BLOCK DATA
This is the function to confirm buoy data in blocks in a list of data.
6. LATEST BUOY DATA
This is the function to display the latest buoy data.
To Next Page
