1 Table of Contents
1 Table of Contents 3
2 General 9
2.1 About this manual 9
2.2 Using the PDF Format 9
2.3 SymbolsUsed 10
2.4 Standards used 11
2.5 Abbreviations Used 12
3 Safety 13
3.1 You should pay attention to this 13
3.2 Warning notes placed on the product 15
3.3 Use as Directed 16
3.4 Prohibited Use 17
4 Product life cycle handling 18
4.1 Transport 18
4.2 Packaging 18
4.3 Storage 18
4.4 Decommissioning 18
4.5 Maintenance and cleaning 19
4.6 Disassembly 19
4.7 System Repair 20
4.8 Disposal 20
5 Approvals 21
5.1 Conformance with UL 21
5.2 CE conformance 22
5.2.1 European Directives and Standards for the machine builder 22
5.2.2 Functional Safety Conformance according to EC Machinery Directive 23
5.3 Conformance with RoHS 23
5.4 Conformance with REACH 23
5.5 Conformance with EAC 24
6 Package 25
6.1 Package supplied 25
6.2 Nameplate 25
6.3 Part number scheme 26
7 Technical description 27
7.1 The S700 family of digital servo amplifiers 27
7.2 Technical data 30
7.2.1 Rated data 30
7.2.2 Inputs, outputs, aux. voltage supply 31
7.2.3 Connectors 31
7.2.4 Recommended tightening torques 31
7.2.5 Fusing 32
7.2.6 Ambient Conditions, Ventilation, and Mounting Position 32
7.2.7 Conductor cross-sections 33
7.3 Motor holding brake 34
7.4 LED display 35
7.5 Grounding system 35
7.6 Dynamic braking (brake circuit) 35
7.7 Switch-on and switch-off behavior 36
7.7.1 Behavior in standard operation 37
7.7.2 Behavior in the event of an error (with standard setting) 38
S748-772 Instructions Manual | Table of Contents
Kollmorgen | kdn.kollmorgen.com | July 2019 3
