9.13 Electronic Gearing, Master-Slave operation
In the case of the “electronic gearing” functionality (see setup software and description of
GEARMODE parameter), the servo amplifier is controlled by a secondary feedback device
as a slave.
It is possible to set up master/slave systems, use an external encoder as a setpoint encoder
or connect the amplifier to a stepper motor control.
The amplifier is parameterized using the setup software (electronic gearing, parameter
GEARMODE).
The resolution (number of pulses per revolution) can be adjusted.
If input X1 is used without the X1 power supply (pins 2, 4, 10, 12), e.g. master-slave oper-
ation with other servoamplifiers, the monitoring of this power supply must be switched off in
order to prevent error message F04 from appearing. To do this, you must change Bit 20 of
the DRVCNFG2 parameter (see ASCII object reference in the online help).
9.13.1 Encoder control types
The following types of external encoder can be used for control:
S700 controlled by Frequency
limit
Connector Wiring
diagram
GEARMODE
Encoder BiSS digital 1,5 MHz X1 (➜ # 80) 11, 12
SinCos Encoder ENDAT 2.1 350 kHz X1 (➜ # 81) 8
Encoder ENDAT 2.2 1,5 MHz X1 (➜ # 82) 13
SinCos Encoder HIPERFACE 350 kHz X1 (➜ # 83) 9
SinCos Encoder without data channel 350 kHz X1 (➜ # 85) 6, 7
ROD* (AquadB) 5V 1,5 MHz X1 (➜ # 87) 30
ROD* (AquadB) 5V 350 kHz X1 (➜ # 88) 10
ROD* (AquadB) 24V 100 kHz X3 (➜ # 90) 2
SSI 5V 1,5 MHz X1 (➜ # 92) 25
Step/direction 5V 1,5 MHz X1 (➜ # 95) 27
Step/direction 24V 100 kHz X3 (➜ # 95) 1
With a "PosI/O" or "PosI/O-Monitor" expansion card in slot 2 or 3 ((➜ # 143) ff), the following
encoder types can be used:
S700 controlled by Frequency
limit
Connector Wiring
diagram
GEARMODE
SSI 5V 1,5 MHz X5 (➜ # 146) 5
ROD* (AquadB) 5V 1,5 MHz X5 (➜ # 148) 3
Step/direction 5V 1,5 MHz X5 (➜ # 148) 4
* ROD is an abbreviation for incremental encoder
