S748-772 Instructions Manual | 2 General
2.3 Symbols Used
Warning Symbols
Symbol Indication
Indicates a hazardous situation which, if not avoided, will result
in death or serious injury.
Indicates a hazardous situation which, if not avoided, could res-
ult in death or serious injury.
Indicates a hazardous situation which, if not avoided, could res-
ult in minor or moderate injury.
Indicates situations which, if not avoided, could result in prop-
erty damage.
This symbol indicates important notes.
Warning of a danger (general). The type of danger is specified
by the text next to the symbol.
Warning of danger from electricity and its effects.
Warning of danger from hot surface.
Warning of danger from suspended loads.
Warning of danger from automatic start.
Drawing symbols
Symbol Description Symbol Description
Signal ground Diode
Chassis ground Relay
Protective earth Relay switch off delayed
Resistor Normally open contact
Fuse Normally closed contact
10 Kollmorgen | kdn.kollmorgen.com | July 2019
