6 Package
6.1 Package supplied
When an amplifier from the S700 series is ordered (order numbers (ā # 159)), the following
is supplied:
Servo amplifier S700 with shielding plate and shield clamps
Product Safety Guide S700 (printed)
Online documentation and setup software on CD-ROM
Mating connectors X3A, X3B, X4, X9A, X9B
The mating SubD connectors are not part of the package!
Accessories : (must be ordered separately, if required; description see accessories
manual)
Hybrid motor cable (prefabricated) for single cable connection
Motor cable as a cut-off length
Feedback cable (prefabricated)
or both feedback connectors separately, with the feedback cable as a cut-off length
External brake resistor BAS(U)
Communication cable to the PC (ā # 104) for setting parameters from a PC
Power cable, control cables, fieldbus cables (as cut-off lengths)
Mains choke if mains voltage is more than 3% asymmetrical
6.2 Nameplate
The nameplate is attached to the side of the servo amplifier. The information described below
is printed in the individual fields. Picture similar to the original nameplate.
