Page #29 background image
Expansions
Slot 1
Expansion cards in slot 1 can be combined with F2 Option in slot 2. More combinations of
slot 1 and slot 2 expansion cards are not possible.
I/O-14/08 expansion card, ( # 127)
PROFIBUS expansion card, ( # 130)
sercos® II expansion card, ( # 131)
DeviceNet expansion card, ( # 133)
SynqNet expansion card, ( # 136)
FB-2to1 expansion card, ( # 138)
-2CAN- expansion module, separated connectors for CAN bus and RS232, ( # 140)
Slot 2
PosI/O expansion card,( # 143)
PosI/O-Monitor expansion card, ( # 143)
F2 Option, controlled fan, later insertion not possible,( # 152), can be combined with
expansion cards in slot 1.
Slot 3
PosI/O expansion card, ( # 152)
PosI/O-Monitor expansion card, ( # 152)
F2 Option, controlled fan, later insertion not possible, ( # 152)
Safety expansion card (S3) S1-2 (SIL CL3), ( # 155)
Safety expansion card (S4) S2-2 (SIL CL2), ( # 153)
Several third-party expansion cards (ModBus, LightBus, FIP-IO etc. please contact the man-
ufacturer for further information)
Macro programming
More information can be found in our KDN Makro-Programming.
62.5μs / 250μs / 1ms / 4ms / 16ms / IDLE / IRQ
128 kByte memory
IEC 61131 structured text
400 easy instructions every 62.5 μs
CAN objects for multi axis control
S748-772 Instructions Manual | 7 Technical description
Kollmorgen | kdn.kollmorgen.com | July 2019 29
