Configuration CP3003-SA
Page 4 - 18 ID 1052-6929, Rev. 3.0
D R A F T — F O R I N T E R N A L U S E O N L Y
4.2.17 General Purpose Input Register (GPIN)
The General Purpose Input Register holds the general purpose input signals of the rear I/O
CompactPCI connector J2. This register can be used only if the CP3003-SA is ordered as a rear
I/O version and the rear I/O GPIO operation is configured through the dedicated rear I/O module
configuration signal on the CompactPCI J2 connector.
Table 4-19: General Purpose Input Register (GPIN)
REGISTER NAME GENERAL PURPOSE INPUT REGISTER (GPIN)
ADDRESS 0x293
BIT NAME DESCRIPTION
RESET
VALUE
ACCESS
7 - 5 Res. Reserved 000 R
4 GPI4 General purpose input 4 signal (3.3V LVTTL):
0 = Input low
1 = Input high
1R
3 GPI3 General purpose input 3 signal (3.3V LVTTL):
0 = Input low
1 = Input high
1R
2 GPI2 General purpose input 2 signal (3.3V LVTTL):
0 = Input low
1 = Input high
1R
1 GPI1 General purpose input 1 signal (3.3V LVTTL):
0 = Input low
1 = Input high
1R
0 GPI0 General purpose input 0 signal (3.3V LVTTL):
0 = Input low
1 = Input high
1R
Note ...
The CP3003-SA provides pull-up resistors on the rear I/O signal pins GPI[4:0],
which leads to the default setting “input high” if the inputs are not connected.
The general purpose inputs support 3.3 V LVTTL signaling only (not 5V
friendly).
