CP3003-SA CP-RIO3-04 Rear I/O
ID 1052-6929, Rev. 3.0 Page C - 3
D R A F T — F O R I N T E R N A L U S E O N L Y
C. CP-RIO3-04 Rear I/O Module
C.1 Overview
The CP3003-SA provides optional rear I/O connectivity for peripherals, a feature which may be
particularly useful in specialized CompactPCI systems. Some standard PC interfaces are
implemented and assigned to the front panel and to the rear I/O connector J2 on the
CP3003-SA. When the CP-RIO3-04 rear I/O module is used, the signals of some of the main
board/front panel connectors are routed to the module interface.
To support the rear I/O feature, a 3U CompactPCI backplane with rear I/O support is required.
The CP3003-SA with rear I/O is compatible with all standard CompactPCI passive backplanes
with rear I/O support.
The CP-RIO3-04 rear I/O module provides the following interfaces.
• CompactPCI rear I/O
• Two USB 2.0 ports
• Two Gigabit Ethernet ports without LED signals
• Two COM ports
• VGA analog port
•Two SATA ports
• Power supply management
C.2 Technical Specifications
Table C-1: CP-RIO3-04 Rear I/O Module Main Specifications
CP-RIO3-04 SPECIFICATIONS
External Interfaces
USB Two USB 2.0 interfaces; two 4-pin connectors
VGA One VGA interface; 15-pin D-Sub connector
Ethernet Two Gigabit Ethernet interfaces implemented as dual RJ-45 connector without LEDs
COM Two onboard, RS-232 serial ports with full modem support, COMA (COM1) and
COMB (COM2)
On the 8 HP version, the serial ports are routed to the front panel and implemented as
two 9-pin D-Sub connectors.
Internal Interfaces
SATA Two SATA interfaces implemented as two 7-pin, L-form standard SATA connectors
Peripheral Control One 10-pin, 2.54 mm onboard connector for power supply management
Compact PCI CompactPCI connector for connecting rear I/O to the backplane
COM Two COM ports implemented as two 10-pin, 2.54 mm onboard connectors (4 HP only)
full modem support
General
Temperature Range Operational: 0°C to +60°C
Storage: -55°C to +85°C
Climatic Humidity 93% RH at 40°C, non-condensing (acc. to IEC 60068-2-78)
Dimensions 100 mm x 80 mm
Board Weight 4 HP: 120 grams
8 HP: 150 grams
