2.11.3.1 Front Panel USB Connectors J5 and J6
The CP3003-SA has two USB 2.0 interfaces that are implemented as two 4-pin, type A USB con-
nectors on the front panel, J5 and J6, with the following pinout:
2.11.4 Integrated Processor Graphics Controller
The 3
rd
gen. Intel® Core™ i7 processor includes a highly integrated processor graphics
controller delivering high-performance 3D, 2D graphics capabilities. The integrated processor
graphics controller has three independent display pipes allowing for support of multiple display
configurations.
Integrated processor graphics controller features:
• Intel® Dynamic Video Memory Technology
• Intel® Smart 3D/2D Display Technology
• DirectX Video Acceleration (DXVA) support for accelerating video processing
(Full AVC/VC1/MPEG2 HW Decode)
• DirectX11, DirectX10.1, DirectX10 and DirectX9 support
• OpenGL 3.0 support
• Two digital ports capable of driving resolutions up to 2560 x 1600 pixels @ 60 Hz through
DisplayPort and up to 1920x1200 pixels @ 60Hz using HDMI/DVI
• One analog port (VGA) capable of driving resolutions up to 2048 x 1536 pixels with 32-
bit color @ 75 Hz
Note ...
When connecting peripheral devices to USB ports, always ensure that
appropriate cables are used.
Note ...
The CP3003-SA host interfaces can be used with maximum 500 mA continu-
ous load current as specified in the Universal Serial Bus Specification, Revision
2.0. Short-circuit protection is provided. All the signal lines are EMI-filtered.
Table 2-8: Maximum Resolution in 3-Display Configurations
DIGITAL PORT DIGITAL PORT ANALOG PORT
DisplayPort
2560x1600 pixels @ 60Hz
DisplayPort
1920x1200 pixels @ 60Hz
VGA Port
1920x1200 pixels @ 60Hz
HDMI/DVI
2560x1600 pixels @ 60Hz
via a cable adapter
HDMI/DVI
1920x1200 pixels @ 60Hz
via a cable adapter
VGA Port
1920x1200 pixels @ 60Hz
Figure 2-1: USB Connectors
J5 and J6
J5
J6
4231
4231
Table 2-7: USB Connectors J5 and J6 Pinout
PIN SIGNAL FUNCTION I/O
1 VBUS USB power O
2 D- USB 2.0 differential pair data - I/O
3 D+ USB 2.0 differential pair data + I/O
4 GND Ground for power return --
